Push to Exit Button Surface Narrow Size Backbox SPDT Normal Open / Closed

SHENZHEN CAMEL SECURITY CO.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
SHENZHEN CAMEL SECURITY CO.,LTD
City: Shenzhen
Province/State: Guangdong
Country/Region: China
Tel: 86-755-29412290
Contact Person:
Mr Hanson GUI

Push to Exit Button Surface Narrow Size Backbox SPDT Normal Open / Closed

Brand Name : CAMEL
Model Number : Z35D
Certification : CE RoHS
Place of Origin : China
MOQ : 10pcs
Price : reasonable prices
Payment Terms : T/T, Western Union, MoneyGram
Supply Ability : 60,000 units per month
Delivery Time : within 5 working days
Packaging Details : paperbox for each unit; carton box for 100pcs at dimension 51*46*25cm
Product Name : Press to Exit Button
Size : 85L*35W*27H(mm)
Material : Zinc Alloy Housing, Metal Button
Output Contact : NO/NC/COM
Mechanical Life : 500,000 tested
Package : 100pcs/15kg/51*46*25cm/ctn
Contact Now

Push to Exit Button Surface Narrow Size Backbox SPDT Normal Open / Closed


Product Introduction


Exit Button Specialists Camel Security offer a wide range of market leading access control door exit buttons and door release buttons. Our products covers push to exit button, press to exit button, Infrared sensor No touch exit button, touch sensor exit and keyswitch.

Exit buttons also refer to push to exit button or press to exit button & request to exit button. They are an integral part of all access control systems, doors can be secured but retain the ability to exit easily.


Z35D is a small narrow size request to exit button with backbox and zinc alloy housing. They are typically used in narrow frame doors and surface mounted.


Z35D is upgrade from our Z30 (normal open type narrow size surface mount push button). Z30 already sell to over 80+ countries with 0.01% error rate in the past 6 years. Z35D already proved good quality with big requirement in the overseas markets foreign countries. We recommend this to you.


Exit button is very common and frequently used in access control system, it is often used in public, banks, small, medium and large sized enterprised, department stores and residences etc.


Products Key Words


push button, exit push button, push exit button, push to exit, press to exit, request to exit, Egress device, exit button, exit button with back box, access control, SPDT door exit button


Key Features


1, NO (normally open) NC (normally close) double features. Much better and market demands

2, zinc alloy housing with backbox, it is good for surface mounted. easy to install.

3, ultra narrow size is designed for narrow frame and elegant style

4, 500,000 cycles tested, assure good quality

5, CE RoHS Certificated, CE at 2014/30/EU and RoHS at 2011/65/EU

6, 3 years warranty, we have confident about our products quality and provide 3 years warranty for our push button products.

7, unique zinc alloy metal case designed by Camel Security itself, you can find here and only here


Technical Parameter


Size85L*35W*27H(mm)
MaterialZinc Alloy Housing, Metal Button
Current3A @36V DC Max.
Output ContactNO/NC/COM
Mechanical Life500,000 tested
Working Temperature10‐55℃ (14-131F)
Working Humidity0-95% (non-condensing)
Standard Package100pcs/51*46*25cm/15kg/ctn

Products Details Introduction
